Description
-
Powerful 1200w motor with atwo-speed mechanical gearbox.
-
13kg in total weight.
-
Suitable for drilling up to 40mm diameter by 50mm depth.
-
CutSmart Technology designed to protect your motor and cutter, prolonging tool life.
-
Quick release interchangeable handle allowing you to operate the mag drill from either side and improving accessibility.
-
Internal cabling reduces the risk of damage and downtime for your magdrill.
-
Internal cooling keeping your mag drill cool and allowing you to drill for longer.
-
Small in size (514mm), this magnetic drill performs in difficult environments.
-
40mm max cutter diameter.
-
Dual motor protection system to prolong the machines life and prevent unwanted wear.
SPECIFICATION
| Model Number |
Element 40/1 / Element 40/3 |
|---|---|
| Motor Specification |
110V 1200W / 230V 1200W |
| No load RPM |
Low Gear: 300 RPM/High Gear: 600 RPM |
| Max Cutting Capacity |
40 x 50mm deep |
| Drill Chuck Capacity |
13mm |
| Overall Dimension |
Height: 510mm / Width: 185mm with Capstan / Length: 285mm with Guard |
| Machine Weight |
13.65kg |
| Magnetic Adhesion |
10,000N |
| Magnet Size |
180mm x 90mm |
| Safety Features |
Cutsmart Technology / Fixed Guard /Magnetic Detection/ Mechanical Clutch |
